Aluminium Alloy 7068 Round Bars
Customer service is online. Enter the chat to get the latest quotation.
Spot stock
Customize
Factory direct sale
7 days delivery
| Aluminium Alloy 7068 Round bars |
Instruction
Aluminium Alloy 7068 is a high-strength alloy that has excellent mechanical properties and is often used in applications that require high tensile strength, high fatigue resistance, and good toughness. This alloy is mainly composed of aluminum, zinc, and magnesium, and it exhibits superior corrosion resistance as compared to other aluminum alloys.
Products Description
STANDARD SPECIFICATIONS FOR ALUMINIUM 7068 ROUND BARS
Aluminium Alloy 7068 Round Bars Standards
ASTM B221, B211, B565, B316, ISO AlMg4,5Mn0,7
7068 Aluminium Round Bars Dimensions
EN, DIN, JIS, ASTM, BS, ASME, AISI
7068 Aluminum Round bar size
Diameter: 3-~800mm
Aluminium Alloy 7068 Hex Bar size
2-100mm A/F
Aluminium Alloy 7068 Flat bar size
Thickness: 2 -100mm / Width: 10 to 500mm
Aluminium Alloy 7068 Square bar size
4 to 100mm
Aluminium Alloy 7068 Rectangular Size
33 x 30mm to 295 x 1066mm
Aluminium Alloy 7068 Bars Condition
Hardened & tempered, annealed
ASTM B211 ALUMINIUM 7068 ROUND BAR EQUIVALENT GRADES
| Element | Content (%) |
|---|---|
| Zinc, Zn | 8.3 |
| Magnesium, Mg | 3 |
| Copper, Cu | 2.4 |
| Iron, Fe | 0.15 |
| Zirconium, Zr | 0.15 |
| Silicon, Si | 0.12 |
| Manganese, Mn | 0.1 |
| Titanium, Ti | 0.1 |
| Chromium, Cr | 0.05 |
| Other (each) | 0.05 |
| Other (total) | 0.15 |
| Aluminum, Al | Remainder |
CHEMICAL COMPOSITION OF ALUMINIUM 7068 ROUND BARS
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 641 MPa | 93 ksi |
| Yield strength | 590 MPa | 85.7 ksi |
| Elongation | 8% | 8% |
MECHANICAL PROPERTIES OF ALUMINIUM 7068 ROUND BARS
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 641 MPa | 93 ksi |
| Yield strength | 590 MPa | 85.7 ksi |
| Elongation | 8% | 8% |
One of the most significant advantages of Aluminium Alloy 7068 is its exceptional strength-to-weight ratio, making it an ideal choice for aerospace and transportation industries where weight reduction is crucial. Additionally, this alloy has excellent weldability and can be easily fabricated into various shapes and sizes.
Furthermore, Aluminium Alloy 7068 is highly resistant to corrosion, which makes it an ideal material for outdoor applications such as marine structures, offshore drilling rigs, and other industrial equipment.
