1235 Aluminum Foil Roll
Customer service is online. Enter the chat to get the latest quotation.
Spot stock
Customize
Factory direct sale
7 days delivery
| 1235 Aluminum Foil |
What Is 1235 Aluminum Foil?
1235 aluminum foil belongs to 1000 series aluminum foil, which is pure aluminum foil, with an aluminum content of no less than 99.35%. This product is widely used in cable, tape, and battery foil because of its excellent anti-rust characteristics, formability, and solubility.
Specifications And Parameters Of Aluminum Foil Alloy 1235
| Feature / Specification | Details |
| Alloy Grade | 1235 |
| Chemical Composition (%) | - Si 0.2 max - Mn 0.9 max - Fe 0.8 max - Zn 0.3 max - Cu 0.2 max |
| Physical Properties | - Density 2.7g/cm^3 - Melting Point 660°C - Recrystallisation temperature 200-300°C |
| Surface Treatment | Bright Annealed |
| Mechanical Properties | - Yield stress 25 MPa - Ultimate tensile stress 98 MPa - Elongation 15% min - Hardness 50 HV min |
| Thickness Range | 0.006 mm – 0.2 mm |
| Width Range | Up to 1600 mm single roll or multiple rolls |
| Production Methods | Hot rolling or Cold rolling depending upon desired thickness level |
| Finish | Uncoated |
| Use Cases | Flexible Packaging, Specialty Industrial Applications |
| Typical Applications | Food Wrappers, Pharmaceutical Blister Packaging, Tobacco Products, Batteries, Electronic Devices, Building Construction Materials, Solar Panels |
| Performance Attributes | Easy printing, good heat sealing, excellent moisture barrier, good formability, tear resistance, low reactivity with food stuffs |
Applications
Flexible Packaging
1235 aluminum foil is widely used in flexible packaging of food, medicine and cosmetics. All can be divided into medical packaging aluminum foil, 1235 aluminum foil for cigarette packing.
1235 aluminum foil provides excellent barrier protection against moisture, light and oxygen, and can be easily made into different shapes and sizes.
Insulation
1235 aluminum foil is a popular choice for insulation due to its excellent thermal conductivity and reflectivity. It is widely used in cables and is also heavily used in the construction industry for building insulation, and in the automotive industry for engine parts insulation.
Specifications of aluminum foil for 1235 cables:
Alloy state: 1235-o
Thickness: 0.006～0.04
Processing method: After aluminum-plastic compounding, it is processed into narrow strips.
Application: Wrapping weak wires for shielding.
1. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2. Do you have any certificates ?
Our products passed inspection of SGS, ISO Quality is priority!Every worker keeps the QC from the very beginning to the very end,Quality control department especially responsible for quality checking in each process.
3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the cost of freight.
4. Why should you buy from us not from other suppliers?
We are experts in the supplying of materials to meet the individual requirements of a project, regardless of size, scope or difficulty. As a specialized supplier of highly qualified products such as Seamless/Welded Pipe and Tube, Plate and Equipment .
