| 5083 H112 Aluminum Sheet |
Aluminum plate 5083 belongs to Al-Mg series alloy. It is the corrosion-resistant alloy with the highest strength among non-heat-treated alloys. Suitable for welding structures. Has good sea water resistance and low-temperature performance. So, 5083 aluminum alloy sheet becomes the best choice for marine aluminum.
Aluminum Plate 5083 Quality Data Sheet / Characteristics / Chemistry Composition:
| Alloy | Element | Si | Fe | Cu | Mn | Mg | Cr | Ti | Zn | Al |
|---|---|---|---|---|---|---|---|---|---|---|
| 5083 | Standard Value | ≤0.4 | ≤0.40 | ≤0.10 | 0.4~1.0 | 4.0-4.9 | 0.05~0.25 | ≤0.15 | ≤0.25 | Remainder |
Aluminum 5083 Sheet Characteristics
1. Effectively resist corrosive substances. Such as the atmosphere, freshwater, seawater, neutral inorganic salt solutions, most acids.
2. Good solderability. Such as gas welding, arc welding, contact spot welding and wire welding.
3. Good formability and high fatigue strength. It cannot be strengthened by heat treatment.
5083 Aluminum Sheet Mechanical Properties
| Tensile strength σb (MPa) | 110-136 |
| Conditional yield strength σ0.2(MPa) | ≥110 |
| Elongation δ10(%) | ≥20 |
| Elongation δ5(%) | ≥12 |
5083 Aluminum Sheet Tempor
5083-H116 For products made of 5xxx series alloys with a magnesium content of 4% or more. These products have the required mechanical properties and resistance to spalling and corrosion.
5083-H111, full annealed products that have undergone a moderate amount of work-hardening, but can’t reach the hardness of the H11 condition.
5083-H112: Applicable to products that are hot rolled. The mechanical properties of products in this condition are required by regulations.
5083-H321: This is suitable for processing aluminum materials with magnesium content greater than 4%, and the degree of work hardening in both hot and cold working is slightly less than that of H32. The technical parameters of H116 are demanding, with strict requirements for anti-corrosion properties and magnesium content; however, H321 has good performance stability.
