Aluminium Composite Panel 2~4mm

2-4mm aluminum composite panel is a widely used building material due to its many advantages. It is lightweight, durable, and easy to install. The panel is made up of two aluminum sheets that are bonded to a polyethylene core. This combination provides excellent weather resistance, fire resistance, and sound insulation.

Send Inquiry

Chat Now

Customer service is online. Enter the chat to get the latest quotation.

Spot stock
Customize
Factory direct sale
7 days delivery

Product Introduction

Introduce

The aluminum composite panel can be used in a variety of applications, including cladding, ceilings, and partitions. It is also a popular material for signage and advertising boards because of its flat surface, which is perfect for digital printing.

Furthermore, the panel can be easily shaped and curved, making it a versatile and visually appealing option. This allows architects and designers to create unique and modern building facades that stand out.

In addition to its aesthetic benefits, the aluminum composite panel is also eco-friendly and recyclable. It is considered a sustainable material because it reduces energy consumption during fabrication, transportation, and installation.

Overall, the 2-4mm aluminum composite panel is a reliable and cost-effective building material that offers numerous design possibilities. Its positive attributes make it a desirable choice for any construction project.

relevant information

Specifications

2~4mm Aluminium composite panel/sheet/board(ACP)

1.PVDF/PE Coated
2.thickness:2 - 4mm
3.Size:1220X2440mm
4.aluminum:0.07-0.5mm

Alucobond acp,acp,aluminium composite panel, Exterior aluminum composite panel(acp),aluminum exterior wall panels

1.Specifications

Standard size

1220*2440*3mm and 1220*2440*4mm

Accepted Width

Max:1580mm

Accepted Length

Max:6000mm

Accepted Thickness

2mm,3mm,4mm,5mmm,6mm

Aluminum alloy thickness

0.10mm	0.15mm	0.18mm	0.21mm	0.25mm
0.3mm	0.35mm	0.40mm	0.45mm	0.50mm

Weight

5 kg/m² base on 4*0.4mm

Nonstandard

sizes are available according your requirement

2.Quality

1) No flake,no rubbles,no vestige and no pulverization.
2)Under common temperatures and radiation, no color deferent.
3)According to international test standard,all the tested items are satisfied with high-class.
4)Our products with PVDF coating which produced under GB/T17748-1999 is with 70% PVDF.and under common environment,we can guarantee 15~20 years;and for FR products,it is good at fireproof,and the FR grade is B1(according to the standard Q B8624).

3.Application scope

1) Building exterior curtain walls..

2) Decoration and renovation additions for old buildings

3) Decoration of interior walls, ceilings, bathrooms, kitchens and balconies

4) Shop door decorations

5) Advertisement board display platforms and signboards

6) Wallboards and ceilings for tunnels..

7) Industrial materials, materials for vehicles and boats

4.Material

1) Top: aluminum alloy(3003) coated with Fluorin carbon resin (PVDF) or Polyester resin (PE) roasting painting.
2) Core:non-toxic polyethylene or fireproof material(B1).
3) Back:aluminium alloy sheet coated with polyester resin painting.
4) Surface finish: PVDF / PET coated,brushed finish, mirror finish, wooden faced,marble faceed ,nano painting ect.
5) Surface coating thickness :25~30 μm 70% KYNAR 500 PVDF or PET.

5.Feature

1)Super werther resistance
2)Light weight easy to process
3)Excellent fire resistance
4)Excellent impact strength
5)Uniform and colorful coating
