3105 H28 Aluminum Sheet

3105 Aluminum Sheet is adding some other elements on the basis of pure aluminum, such as cu, mg, si, mn, etc., the purpose is to improve the strength of aluminum alloy, the final aluminum content is 98%, the chemical composition of 3105 aluminum alloy is as follows.

Aluminum alloy 3105 is essentially a 98% aluminum alloy with minor elements added to increase strength compared to alloys 1100 and 3003.

It cannot be hardened by heat treatment and has good corrosion resistance, formability and weldability.

0.3% copper is added to the 3105 aluminum sheet, and the conductivity is 41%.

The content and processing technology of 3105 aluminum plate, light weight and semi-smooth surface.

Typical applications include general sheet metal fabrication, residential siding, mobile homes, and signage that require higher strength than 1000 series aluminum alloys.

3105 Aluminum Standard

3105 aluminum is formulated for primary forming into forged products. 3105 is the Aluminum Association (AA) designation for this material.

In European standards it will be designated as EN AW-3105. N31 is the British Standard (BS) designation. A93105 is the UNS number. Additionally, the EN chemical name is AlMn0,5Mg0,5.

It originally received the standard name in 1960.

Difference Between 3003 And 3105 Aluminum

3105 aluminum alloy has good corrosion resistance, good plasticity and machinability, and good gas welding and arc welding performance. The strength of 3105 aluminum is slightly higher than that of 3003 aluminum, and other properties are similar to 3003 aluminum alloy. 3105 aluminum has good anti-rust performance, good electrical conductivity, and the electrical conductivity can reach 41%. The 3105 aluminum plate has high plasticity in the annealed state, but still has good plasticity in the semi-cold hardened state. Low plasticity, good corrosion resistance, good weldability, and poor cutting performance in the quenched state.

The Characteristics Of 3105 Aluminum Alloy

1. Deep drawability, the deep drawing performance of 3105 aluminum alloy in O state is better than that in H26 state, and the deep drawing performance of 3105 aluminum alloy before cryogenic treatment is better than that after 24h;

2. Plasticity, 3105 aluminum alloy has high plasticity in the annealed state, good semi-cold work hardening plasticity, low cold work hardening plasticity, and poor machinability;

3. Weldability, it is worth mentioning that 3105 aluminum alloy has excellent weldability and is suitable for all existing welding technologies, among which arc welding is the best method;

4. Cold workability, even under cold tempering conditions, the cold workability of 3105 aluminum alloy is very good. 3105 aluminum sheet no more than 1/16 inch thick can have a bend radius between 1/2 and 1 for all tempers;

5. By definition, 3105 aluminum alloy may be forged in the temperature range of 950 to 700 F if desired. Hot working can be done at 700 to 400 F;

6. Conductivity, with 0.3% copper added, the conductivity can reach 41%;

7. Anti-rust, 3105 aluminum is a widely used anti-rust aluminum;
