Aluminium alloy 6063 is a medium strength alloy and is also referred to as an architectural alloy. It generally has a good surface finish and high corrosion resistance. Alloy 6063 is readily suited to welding, can be easily anodised and is most common in T6 temper. T4 temper is very good for forming.







Aluminium 6063 Sheets Specification

Temper: 6063 –T6

Thickness: 0.5.0mm--500mm

With: 500mm--2000mm

Length: 1000mm--3000mm

Surface: Mill finish, Bright finish, paper interleaved, one side film, both sides film.

Aluminium 6063 Sheet & Plates Equivalent Grades :

UNS	WNR	DIN	EN	ISO	BS (OLD)	USA
A96063	3.32206	AlMgSi0.5	AW-AlMg0,7Si EN AW-6063	AlMg0,7Si	HE9	AA6063

Chemical Composition Of Aluminium Alloy 6063 Sheets & Plates :

Grade	Element
	Al	Si	Fe	Cu	Mn	Cr	Mg	Ti	Zn
6063	Bal	0.40-0.8	0.7	0.15-0.40	0.15	0.04-0.35	0.8-1.2	0.15	0.25

Mechanical Composition Of Aluminium Alloy 6063 Sheets & Plates :

Properties	Metric
Yeild Strength	40 Ksi
Tensile Strength	45 Ksi
Hardness Brinell	95 BHN
Elongation	17 %

Features

Best in class strength,

Dimensional stability,

Good anodization response

Applications

Aircraft

Structure Screw Machine Products

Housings,

Hydraulic Parts

Automotive

marineindustries

Renewable Energy

Mass Transportation

Disclaimer
Every effort is made to ensure that technical specifications are accurate. However, technical specifications included herein should be used as a guideline only. All specifications are subject to change without notice.
