6061 Anodized Aluminum Sheet Overview
6061 anodized aluminum sheet is produced by applying an anodizing process to 6061 aluminum alloy sheets, forming a protective oxidized surface layer. This treatment enhances surface hardness, corrosion resistance, and appearance, making the material suitable for a wide range of industrial and architectural applications. GNEE supplies high-quality 6061 anodized aluminum sheets with stable performance and consistent surface quality.
| Alloy/grade | 6061 |
| Temper | O, T4, T6, T0, T651, F |
| Thickness | 0.3-500mm |
| Width | 500-2800mm |
| Length | 500-16000mm |
| Representative end products | Cell phone ISM card shell, cell phone shell, molds, cars, precise machining etc. |
| Payment | LC, TT, West Union, Kunlun Bank etc. |
| Lead time | 20-35 working days |
6061 Aluminum Plate Chemical Composition
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other | Al |
| 0.4-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Remained |
6061 Aluminum Plate Mechanical Properties
| Tensile strength σb (MPa) | ≥180 |
| Yielding strength σ0.2 (MPa) | ≥110 |
| Elongation rate δ5 (%) | ≥14 |
| Sample diameter (tube) | ≤150 |
| HB | 95-100 |
6061 Anodized Aluminum Sheet Size Range and Tempers
6061 anodized aluminum sheets can be manufactured in a broad range of specifications. Thicknesses typically range from 0.2 mm to 500 mm, while common widths are between 950 mm and 1800 mm. The most widely used tempers are 6061-T6 and 6061-T651, which help ensure that the anodized oxide film is uniform, stable, and meets industry standards.
6061 Aluminum Alloy Composition and Properties
6061 aluminum sheet is an aluminum–magnesium–silicon alloy known for its excellent mechanical properties and processing performance. By adding alloying elements such as magnesium and silicon, along with small amounts of copper and zinc, the alloy achieves improved strength and corrosion resistance compared to pure aluminum. This balanced composition makes 6061 anodized aluminum sheet widely applicable across multiple industries.
6061 Aluminum Sheet Machinability and Workability
6061 aluminum plate offers medium strength and excellent workability. It can be easily cut, bent, drilled, and welded, making it suitable for both standard fabrication and precision processing. In addition, 6061 aluminum exhibits strong resistance to corrosion and oxidation, allowing it to perform reliably in harsh environments over long service periods.
6061 Anodized Aluminum Sheet in Construction Applications
In the construction sector, 6061 anodized aluminum sheet is commonly used for exterior wall decoration and protection, as well as for roofs, doors, and window systems. Its surface can be further treated through anodizing, spraying, or other finishing processes to enhance visual appeal while increasing resistance to weathering and corrosion.
6061 Aluminum Anodizing Process and Surface Benefits
After anodizing treatment, the surface of 6061 aluminum plate forms a dense and uniform aluminum oxide film. This oxide layer significantly improves surface hardness and corrosion resistance while also enhancing the overall appearance of the material. Anodizing not only extends the service life of 6061 aluminum sheets but also makes them more suitable for demanding environments and high-end applications.
6061 Anodized Aluminum Sheet Advantages by GNEE
In summary, 6061 anodized aluminum sheet retains the original excellent mechanical and processing properties of 6061 aluminum while gaining superior surface protection and aesthetics through oxidation treatment. These advantages make it a highly competitive material for applications in aviation, automotive, construction, electronics, and other industries.
As a professional aluminum supplier, GNEE provides reliable 6061 anodized aluminum sheet solutions that combine performance, durability, and visual quality to meet diverse engineering and architectural requirements.
